The Navigator Nano S 2 is an ideal diagnostic tool for the Car and Bike IDC 6 environments. This ultra-compact, portable, and affordable VCI (Vehicle Communication Interface) is specifically designed for efficient diagnostic work, especially in confined spaces, offering shops a low-cost entry point into advanced diagnostics.
$1,200.00
When you purchase this kit, you can earn up to $500 in tool credits. These tool credits can be used with us to purchase tool brands like Milwaukee, DeWalt, Craftsman, and more. Contact us to see how much you qualify for and to redeem the credits.
You can use the Navigator Nano S 2 on passenger cars, light commercial vehicles, diesel pickups, and high end super cars. It is a low cost entry level VCI that is perfect for mechanics working in the Car IDC 6 and Bike IDC 6 environments.
Are you having trouble figuring out what tools will work best for you? Let us know what vehicles you work on and we will give you a custom recommendation based on our experience using different diagnostic tools. When we recommend products we will make sure they work on
all of the equipment you diagnose.
The Navigator Nano S 2 is an ideal diagnostic tool for the Car and Bike IDC 6 environments. This ultra-compact, portable, and affordable VCI (Vehicle Communication Interface) is specifically designed for efficient diagnostic work, especially in confined spaces, offering shops a low-cost entry point into advanced diagnostics.
| Tech Specs | PROCESSOR CORTEX M3 STM32F103 72MHz MEMORY External SRAM: 8 MBit organised in 512 K x 16 bit External NAND flash memory: 2 Gbit on 8 bit bus INTERNAL BATTERY Lithium polymer, single cell, 3.7 V 250 mA/h VEHICLE ELECTRICS 12 VDC vehicle systems EXTERNAL POWER SUPPLY 8 ÷ 16 V WIRED CONNECTION Virtual RS232 via USB 2.0 device WIRELESS CONNECTION Bluetooth Class1 ELECTRONIC SWITCHING 2 way, 13 independent positions DIAGNOSTICS CONNECTOR OBD ENVIRONMENTAL Operating temperature: 0 ÷ 50 °C Storage temperature: -20 ÷ 60 °C Operating relative humidity: 10% ÷ 80% non-condensing DIMENSIONS 51x23x100 mm WEIGHT 72 g PROTOCOLS SUPPORTED Blink codes, K, L (with 60mA current protection) ISO 9141-2, ISO 14230, CAN ISO 11898-2, CAN ISO 11898-3, SAE J1850 PWM and VPW STANDARDS Directive: 1999/5/EC Safety: EN 60950-1 Electromagnetic Compatibility: EN 301 489-1, EN 301 489-17 Radio systems: EN 300 328-2 |
|---|
